customized top quality EMC Locknut

Model
HX-LN
Code
7415339000
Material
Brass ,nickel plated .
Size
M12-M100 PG7-PG63 G1/2-G3 NPT1/2-NPT3
Contact Now
customized top quality EMC Locknut
customized top quality EMC Locknut
customized top quality EMC Locknut
customized top quality EMC Locknut
customized top quality EMC Locknut
customized top quality EMC Locknut
customized top quality EMC Locknut


















































































































































































规格

Item
厚度 H

Thickness
扳手径

Spanner Size
产品编号

Code
M12x1.5 3 14 HX-LNM12EMC
M14x1.5 3 17 HX-LNM14EMC
M16x1.5 3 18 HX-LNM16EMC
M18x1.5 3 20 HX-LNM18EMC
M20x1.5 3 22 HX-LNM20EMC
M22x1.5 3.2 24 HX-LNM22EMC
M24x1.5 3.5 27 HX-LNM24EMC
M25x1.5 3.5 27 HX-LNM25EMC
M27x1.5 4 30 HX-LNM27EMC
M30x1.5 4 32 HX-LNM30EMC
M32x1.5 4 35 HX-LNM32EMC
M33x1.5 4 36 HX-LNM33EMC
M36x1.5 4 40 HX-LNM36EMC
M37x1.5 4 40 HX-LNM37EMC
M40x1.5 4.5 45 HX-LNM40EMC
M42x1.5 5 45 HX-LNM42EMC
M47x1.5 5.5 50 HX-LNM47EMC
M48x1.5 5.5 52 HX-LNM48EMC
M50x1.5 5.5 55 HX-LNM50EMC
M54x1.5 5.5 57 HX-LNM54EMC
M60x1.5 6 64 HX-LNM60EMC
M63x1.5 6 68 HX-LNM63EMC
M64x2 6 68 HX-LNM64EMC
M72x2 8.5 78 HX-LNM72EMC
M75x2 8.5 78 HX-LNM75EMC
M80x2 9 88 HX-LNM80EMC
M88x2 9 94 HX-LNM88EMC
M100x2 9 110 HX-LNM100EMC

























































































































































































规格

Item
厚度 H

Thickness
扳手径

Spanner Size
产品编号

Code
PG7 3 15 HX-LNPG7EMC
PG9 3 18 HX-LNPG9EMC
PG11 3 21 HX-LNPG11EMC
PG13.5 3 23 HX-LNPG13.5EMC
PG16 3.2 25 HX-LNPG16EMC
PG19 3.5 27 HX-LNP19EMC
PG21 4 30 HX-LNPG21EMC
PG25 4 35 HX-LNPG25EMC
PG29 4 40 HX-LNPG29EMC
PG36 5.5 50 HX-LNPG36EMC
PG42 6 57 HX-LNPG42EMC
PG48 6.5 64 HX-LNPG48EMC
PG63 8.5 78 HX-LNPG63EMC
G1/2 3 23 HX-LNG1/2EMC
G3/4 4 30 HX-LNG3/4EMC
G1 4 40 HX-LNG1EMC
G1-1/4 5.5 50 HX-LNG1-1/4EMC
G1-1/2 5.5 57 HX-LNG1-1/2EMC
G2 6 64 HX-LNG2EMC
G2-1/2 8.5 78 HX-LNG2-1/2EMC
G3 9 94 HX-LNG3EMC
NPT1/2 3 23 HX-LNNPT1/2EMC
NPT3/4 4 30 HX-LNNPT3/4EMC
NPT1 4 40 HX-LNNPT1EMC
NPT1-1/4 5.5 50 HX-LNNPT1-1/4EMC
NPT1-1/2 5.5 57 HX-LNNPT1-1/2EMC
NPT2 6 64 HX-LNNPT2EMC
NPT2-1/2 8.5 78 HX-LNNPT2-1/2EMC
NPT3 9 94 HX-LNNPT3EMC




Q:Are you trading company or manufacturer?

A:We are the factory ,also we are export the goods by ourselves.

Q:How long is your delivery time?

A:Generally we can send out the goods with in 3-7days if the goods are in stock. or It should be 3-7days if the goods are not in stock, it is according to your order quantity.

Q:Do you provide samples? Is it free or not ?

A:Yes, we could offer the samples for free charge but don’t pay the cost of freight.

Q:What is your terms of payment ?

A: Payment <=1000USD,100% in advance. Payment >=1000USD, 30%T/T in advance.

Q: How about the after-sale service?

A: Any feedback or comment are welcomed. We will try to make the best assistant to let you maximum satisfaction.
