适用软管 Conduit size | B | H | T | M | A | 产品编号 Code |
AD10.0 | 25.0 | 26.0 | 12.5 | 4.0 | 6.5 | HX-NBAD10 |
AD13.0 | 30.0 | 26.0 | 12.5 | 4.0 | 6.5 | HX-NBAD13 |
AD15.8 | 30.0 | 26.0 | 12.5 | 5.0 | 6.5 | HX-NBAD15.8 |
AD18.5 | 35.0 | 33.0 | 15.0 | 6.0 | 6.5 | HX-NBAD18.5 |
AD21.2 | 35.0 | 34.0 | 15.0 | 6.0 | 6.5 | HX-NBAD21.2 |
AD25.0 | 42.0 | 38.0 | 16.0 | 6.0 | 11.5 | HX-NBAD25 |
AD28.5 | 42.0 | 42.0 | 16.0 | 6.0 | 11.5 | HX-NBAD28.5 |
AD34.5 | 51.0 | 49.0 | 16.0 | 6.0 | 11.5 | HX-NBAD34.5 |
AD42.5 | 58.0 | 57.0 | 18.0 | 6.0 | 11.5 | HX-NBAD42.5 |
AD54.5 | 73.0 | 70.0 | 20.0 | 7.0 | 12.0 | HX-NBAD54.5 |
Q:Are you trading company or manufacturer?
A:We are the factory ,also we are export the goods by ourselves.
Q:How long is your delivery time?
A:Generally we can send out the goods with in 3-7days if the goods are in stock. or It should be 3-7days if the goods are not in stock, it is according to your order quantity.
Q:Do you provide samples? Is it free or not ?
A:Yes, we could offer the samples for free charge but don’t pay the cost of freight.
Q:What is your terms of payment ?
A: Payment <=1000USD,100% in advance. Payment >=1000USD, 30%T/T in advance.
Q: How about the after-sale service?
A: Any feedback or comment are welcomed. We will try to make the best assistant to let you maximum satisfaction.
